Mini-Circuits’ ZB2PD-63+ is a 2-way 0˚ splitter/combiner covering the 600 to 6000 MHz range with 30W RF input power handling as a splitter, DC passing up to 400mA (200mA each port), 0.8dB insertion loss, 19dB isolation, 0.15dB amplitude unbalance and 2˚ phase unbalance. It comes housed in a rugged aluminum alloy case (1.99×5.26×0.95”) with your choice of N-type or SMA connectors.
לפרטים נוספים: “MCDI”
ט: 077-540-6075
פ: 153-77-540-6051
office@mcdi-ltd.com
www.minicircuits.com
